AVX Modular 48V

Name: AVX Modular 48V
Brand: AVOLUX
SKU: I02.LL.15215

Ürün ikonları

Stok kodu: I02.LL.15215

Kategoriler: 48V Series

AÇIKLAMA

ÜRÜN PDF İNDİR ÜRÜN AİLESİ PDF İNDİR LDT İNDİR

-- Aluminum profile body.

-- With 48V DC input.

-- Intelligent cooling design with passive cooling technology.

-- With DC/DC transformer adapter suitable for Stucchi 48V rail system

-- DALI and 1-10V DIM options available.

-- Wireless DIM and Hot DIM, which are high-tech control systems applications can be made.

-- Standard color options: White, Black, Grey, Dark Grey, RAL9010 Additionally, optional special color options can be applied.

-- High CRI>90 and standard CRI>80 LED options are available.

-- High color compatibility: <3 SDCM .

-- Medium, Wide and Very Wide square frame lens angle options are available.

-- Efficiency up to 115lm/W.

Strength	CRI	Order Code	Kelvin	Lumen
24W	CRI>80	I02.LL.15215 . (..) . (...) . (..) . (..) . (....)	2700K	2651
			3000K	2742
			4000K	2823
			5000K	2909
	CRI>90	I02.LL.15215 . (..) . (...) . (..) . (..) . (....)	2700K	2479
			3000K	2559
			4000K	2639
			5000K	2719

Strength	CRI	Order Code	Kelvin	Lumen
20W	CRI>80	I02.LL.15215 . (..) . (...) . (..) . (..) . (....)	2700K	1987
			3000K	2056
			4000K	2117
			5000K	2180
	CRI>90	I02.LL.15215 . (..) . (...) . (..) . (..) . (....)	2700K	1859
			3000K	1919
			4000K	1979
			5000K	2039

Strength	CRI	Order Code	Kelvin	Lumen
13W	CRI>80	I02.LL.15215 . (..) . (...) . (..) . (..) . (....)	2700K	1325
			3000K	1371
			4000K	1411
			5000K	1453
	CRI>90	I02.LL.15215 . (..) . (...) . (..) . (..) . (....)	2700K	1239
			3000K	1279
			4000K	1319
			5000K	1359

2	Watts - Driving Current	3	CRI/Kelvin	3	CRI/Kelvin	4	Reflector Angle	5	Product Color	Length
24	24W - 350mA	827	CRI>80 - 2700K	927	CRI>90 - 2700K	M.E.	28° - Medium	01	white	534mm
20	19.5W - 350mA	830	CRI>80 - 3000K	930	CRI>90 - 3000K	FL	48° - Flood	02	ral 9010	401mm
13	12.5W - 350mA	840	CRI>80 - 4000K	940	CRI>90 - 4000K	W.F.	36x26° - Wide Flood	03	black	269mm
		850	CRI>80 - 5000K	950	CRI>90 - 5000K			04	gray
								05	dark gray
								06	special color
